产品中心
工业计算机嵌入式系统领导厂商
ECC208H

芯片

Intel® B75 Express Chipset

Intel® B250 Chipset

Intel® Q570 Chipset

CPU

SupportLGA1155 2th/3th Intel® Celeron/Pentium/Core™i3/i5/i7CPU

SupportLGA1151 6th/7th/8th/9th Intel® Celeron/Pentium/Core™i3/i5/i7CPU

SupportLGA1200 10th/11th Intel® Celeron/Pentium/Core™i3/i5/i7CPU

内存

2*DDR3 DIMM SYS Memory Slot,Max 16GB

4*DDR4 DIMM SYS Memory Slot,Support DDRIV

4*DDR4 DIMM SYS Memory Slot,DDR4-2666/2933MHz


ECC208H -7506
ECC208H -2510
ECC208H -5706
系统配置
CPU
SupportLGA1155 2th/3th Intel® Celeron/Pentium/Core™i3/i5/i7CPU
芯片
Intel® B75 Express Chipset
内存
2*DDR3 DIMM SYS Memory Slot,Max 16GB
I/O接口
网络
2*Realtek 8111E 10/100/1000 RJ45Ethernetport
USB
2*USB3.0(Max 4)、2个USB2.0(Max 8)
COM
6*COM(Max)、COM1/2Support232/422/485
LPT
1*LPT
Display
1*HDMI 1*VGA 1*DVI
PS/2
KB/MS
Audio
1*MIC-INport 1*LINE-OUTport 1*LINE-INport“
GPIO
4*GPIO
扩展总线
主板集成
1*PCIE x16、1*PCIE x4、1*PCIE x1,4*PCI / 1*M-SATA
存储器
硬盘
1*2.5 HDD Or 1*3.5 HDD / M-SATA
其他配置
操作系统
Windows xp sp3/ Windows 7/ Windows10/Windows11/Linux ubuntu …
电源类型
ATX Power supply
工作环境
0℃~50℃(HDD),-20℃~+60℃( SSD/M-SATA)
存储环境
-40℃~60℃ ; 5%~90% (Non-condensing state)
尺寸
366×356×180(mm)
系统配置
CPU
SupportLGA1151 6th/7th/8th/9th Intel® Celeron/Pentium/Core™i3/i5/i7CPU
芯片
Intel® B250 Chipset
内存
4*DDR4 DIMM SYS Memory Slot,Support DDRIV
I/O接口
网络
2*Intel I211 10/100/1000 RJ45Ethernetport
USB
6*USB3.0、4个USB2.0(Max 6)
COM
6*COM(Max)、COM1~2 Support 232/232/485
LPT
1*LPT
Display
1*HDMI 1.4 1*HDMI 2.0 1*VGA
PS/2
KB/MS
Audio
1*MIC-INport 1*LINE-OUTport 1*LINE-INport“
GPIO
4*GPIO
扩展总线
主板集成
1*PCIE x16 ,2*PCIE x4(in x8 Slots),2*PCIE x1(in x4 Slots) / 1*M-SATA
存储器
硬盘
1*2.5 HDD Or 1*3.5 HDD / 1*M.2 Key-M 2280 Slot 1*M-SATA
其他配置
操作系统
Windows 7/ Windows10/Windows11/Linux ubuntu …
电源类型
ATX Power supply
工作环境
0℃~50℃(HDD),-20℃~+60℃( SSD/M-SATA)
存储环境
-40℃~60℃ ; 5%~90% (Non-condensing state)
尺寸
366×356×180(mm)
系统配置
CPU
SupportLGA1200 10th/11th Intel® Celeron/Pentium/Core™i3/i5/i7CPU
芯片
Intel® Q570 Chipset
内存
4*DDR4 DIMM SYS Memory Slot,DDR4-2666/2933MHz
I/O接口
网络
2*Intel I226 10/100/1000/2500MB RJ45Ethernetport
USB
8* USB 3.2 Gen 2,2*USB2.0 (Max 4)1*TYPEC(Built in upright Type-A USB 3.0x2)
COM
6*COM(Max)、COM1~2Support232/232/485
LPT
1*LPT
Display
2*HDMI for 4K 1*DP Support 5120 x 3200 @60Hz 1*edp 1920x1080 @60Hz
PS/2
KB/MS
Audio
1*MIC-INport 1*LINE-OUTport 1*LINE-INport“
GPIO
17 bit *GPIO Independent IC
扩展总线
主板集成
1*PCIE x16 1*PCIE x16(in x8 signal) 3*PCIE x4 / 1*M.2 Key-M 2280 Slot 1*Minipce for 4g 1*m2 for 5g 1*m2 ngff for wifi
存储器
硬盘
1*2.5 HDD Or 1*3.5 HDD (max Support 4* SATA 6.0 Gb/s Support RADI 0,1,5,10) / 1*M.2 Key-M 2280 Slot
其他配置
操作系统
Windows10/Windows11/Linux ubuntu …
电源类型
ATX Power supply
工作环境
0℃~50℃(HDD),-20℃~+60℃( SSD/M-SATA)
存储环境
-40℃~60℃ ; 5%~90% (Non-condensing state)
尺寸
366×356×180(mm)
